| Description : |
|
Marvelous Smartrion-Q provides satisfactory results by the effective removing treatment at almost every pigment troubles. It can remove the targeted pigment selectively but very little damage to the dermis and epidermis.
Our PTP Mode has the patient feel little pain and the skin regenerate sooner. |
|
|
|
|
|
|
|
|
| TECHNICAL SPECIFICATIONS |
| Item |
Q-Switched Nd:YAG Laser |
| Wavelength |
1064m/532nm/585nm/650nm
|
| Operating Mode |
1064nm Mode/532nm Mode
585nm Mode/650nm Mode
Genesis Mode |
| Pulse Energy |
1064nm Long pulse |
N/A
|
| 1064nm (Single) |
Max.500mJ |
| 1064nm (Double) |
Max.1.000J |
| 1064nm |
Max.1.500J |
| 532nm (Single) |
Max.250mJ |
| Fractional Mode |
532nm (Double) |
Max.500mJ |
| 585nm |
Max.250mJ |
| 650nm |
Max.150mJ |
| Pulse Width |
Nd:YAG |
5-8ns |
| Spot Size |
2~10mm (1064/532nm)
2mm (585/650nm) |
Pulse Rate
Smart protocol installed in the device |
Max. 1Hz-10Hz |
| Aiming Beam |
Diode 650nm |
| Optional Handpiece |
585, 650 Hand piece
Fractional handpiece |
|
|
|
