| Description : |
|
Q Switched Nd Yag Laser technology has been greatly improved the ability to treat melanocytic lesions and tattoos with the rapidly pulsed Quality Switched Nd-Yag laser. The laser treatment of pigmented lesions and tattoos are based on principle of selective photo thermolysis.
1064nm laser can penetrate into deep layer of the skin, it is easily absorbed by blue and black color pigment.
532nm laser can penetrate into epidermis. Therefore, it is easily absorbed by the green, pink, purple and brown color pigment in epidermis. 1320nm: A moppet tip used along with carbon peel for skin rejuvenation. |
|
|
|
|
|
|
|
|
| TECHNICAL SPECIFICATIONS |
| Laser type |
Q-Switched Nd:YAG Laser |
| Wavelength |
1064nm / 532nm (Optional 1320nm) |
| Pulse energy |
1064nm-1000mj / 532nm- 500mj |
| Frequency |
1 - 10 Hz |
| Pulse width |
10ns |
| Spot Size |
1 - 5 mm |
| Display |
7" Touch Screen LCD |
| Cooling system |
Water + Wind cooling |
| Electrical requirement |
230V AC, 50 Hz |
| Dimensions |
440 x 370 x 1050 mm |
| Weight |
34 Kgs |
|
|
